MS909 - $200 Rebate :This offer is valid through September 15th, 2022.
MaxiSys MS909
The MaxiSys MS909 features a 10-inch touchscreen tablet with Android 7.0 OS powered by an Octa-core processor (2.3GHz Quad + 1.7GHz Quad), substantial 128GB built-in memory to provide diagnostic guidance and test components to confirm repairs. The MS909 features the new MaxiFlash VCI, a combination VCI and vehicle communication tool providing faster dual Wi-Fi vehicle and network communications. The MS909 features front and rear cameras and a rechargeable Lithium battery providing 8 hours of continuous use to ensure you always have the power to scan.
|
Operating System
|
Android 7.0
|
|
Processor
|
Samsung Exynos8895V octa-core Processor (2.3GHz Quad-core Mongoose + 1.7GHz Quad-core A53)
|
|
Memory
|
4GB RAM & 128GB On-board Memory
|
|
Display
|
9.7 inch TFT-LCD with 1536 x 2048 resolution & capacitive touchscreen
|
|
Connectivity
|
-
Wi-Fix2 (802.11 a/b/g/n/ac 2x2 MIMO)
-
BT v.2.1 + EDR
-
GPS
-
USB 2.0 (TWO USB HOST Type A, ONE USB mini device)
-
HDMI 2.0
-
SD Card (Support up to 256GB)
|
|
Camera (rear)
|
|
|
Sensors
|
Gravity Accelerometer, Ambient Light Sensor (ALS)
|
|
Audio Input/Output
|
|
|
Power and Battery
|
|
|
Input Voltage
|
12V/3A Adapter
|
|
Operating Temperature
|
0 to 50°C (32 to 122°F)
|
|
Storage Temperature
|
-20 to 60°C (-4 to 140°F)
|
|
Dimensions (WxHxD)
|
304.4 mm (11.98") x 227.8 mm (8.97") x 42.5 mm (1.67")
|
|
Weight
|
1.66kg (3.66lb.)
|
|
Protocols
|
DoIP, PLC J2497, ISO-15765, SAE-J1939, ISO-14229 UDS, SAE-J2411 Single Wire Can(GMLAN), ISO-11897-2, ISO-11897-3, SAE-J2819 (TP20), TP16, ISO-9141, ISO-14230, SAE-J2610 (Chysler SCI), UART Echo Byte, SAE-J2809 (Honda Diag-H), SAE-J2740 (GM ALDL), SAE-J1567 (CCD BUS), Ford UBP, Nissan DDL UART with Clock, BMW DS2, BMW DS1, SAE J2819 (VAG KW81), KW82, SAE J1708, SAE-J1850 PWM (Ford SCP), SAE-J1850 VPW (GM Class2)
|
|
|
|
 |
|
 |
|
|
|
 |
|
 |
|
Features
-
1. Autel updates provide latest OE level coverage for more than 80 US Domestic, Asian and European vehicles, including supercar
-
2. Exceptional OE-Level functionality from comprehensive OBDII diagnostics & services to advanced ECU coding and programmin
-
3. Automatic system and software updates with real-time push message notifications via internet
-
4. Interactive Data Logging sessions enable direct contact with Autel Support for first-hand troubleshooting of diagnostic bugs and error
-
5. One-stop multitasking designed for ideal management of workshop operations to keep all data files, customer info, and vehicle records well organize
-
6. Cloud-based Data Manager saves customer and vehicle records, scanner data and technician notes
|
|
|
|
|
|
|
